SA 312 TP410 Seamless Boiler Tubing & Heat Exchanger Tube manufacturer in India
UNS S41000, also referred to as sa 213 tp 410 Boiler Tube is a 12% chromium containing martensitic stainless steel grade. This martensitic grade SA 213 TP 410 UNS S41000 Jacketed Tube Heat Exchanger can be heat treated in order to obtain a wide range of mechanical properties. The alloy used in the manufacture of SS UNS S41000 Heat Exchanger Tubes has good resistance to corrosion along with having a high tensile strength and hardness properties.
Manufacturer of A213 TP 410 Heat Exchanger Tubing, UNS S41000 Micro Tube Heat Exchanger stockist in Mumbai, India, ASTM A213 410 Seamless Boiler Tubes price in India.
ASME SA 213 TP 410 Boiler Tube
ASTM A213 TP 410 Boiler Tubing
410 Stainless Steel Heat Exchanger Tubes
In an annealed condition, Stainless Steel 410 Multi Tube Heat Exchanger is ductile in nature and it can be formed. Typically, the ASTM A213 410 Boiler And Heat Exchanger Tube remains magnetic in both i.e. in an annealed condition and heat treated condition as well. Stainless steel grade 410 is best machined in an annealed condition, with the surface speeds being about 60 – 80 feet per minute. At Vishal Steel India, we recommend, performing a post machining decontamination and passivation process.
UNS S41000 Micro Tube Heat Exchanger can also be used in slightly chlorinated as well as in deaerated water. The material used to make A213 TP 410 Heat Exchanger Tubing performs well in oil and gas applications, especially in those conditions where deaerated and low hydrogen sulfide exist. However, the ASTM A213 TP 410 Boiler Tubing alloy is prone to attack from chloride ion containing environments, particularly in oxidizing conditions.
ASME SA 213 TP 410 Boiler Tube operates well in environments which require moderate corrosion resistance along with high mechanical properties.
410 SS Welded Boiler Tubes manufacturers, Stainless Steel 410 Multi Tube Heat Exchanger supplier, SS UNS S41000 Heat Exchanger Tubes exporter in India, Latest SA 213 TP 410 UNS S41000 Jacketed Tube Heat Exchanger Price List
Table of Content
- What is ASME SA 213 TP 410 Boiler Tube?
- ASME SA 213 TP 410 Boiler Tube Price List
- Types of ASME SA 213 TP 410 Boiler Tube
- ASME SA 213 TP 410 Boiler Tube
- ASTM A213 TP 410 Boiler Tubing
- SA 213 TP 410 Stainless Steel Reheater Tubes
- ASTM A213 410 Boiler Reheater Tubes
- Stainless Steel 410 Seamless Boiler Tubes
- SS UNS S41000 ERW Boiler Tubes
- SA 213 TP 410 UNS S41000 Welded Boiler Tubes
- ASME SA 213 410 Finned Tube Reheater
- ASME SA 213 TP 410 Heat Exchanger Tube
- ASME SA 213 Stainless Steel 410 Heat Exchanger Tubes
- A213 TP 410 Stainless Steel Heat Exchanger Tubing
- WNR 1.4006 Seamless Heat Exchanger Tube
- SA 213 TP 410 Welded Heat Exchanger Tube
- A213 Stainless Steel 410 Coiled Tube Heat Exchanger
- A213 TP 410 UNS S41000 Double Tube Heat Exchanger
- ASTM A213 410 Jacketed Tube Heat Exchanger
- ASME SA 213 TP 410 Boiler Tube Specification
- ASME SA 213 TP 410 Reheater Tubes Sizes
- SA 213 TP 410 Stainless Steel Seamless Boiler Tubes Pressure Rating
- SS UNS S41000 Boiler Tubes Chemical Composition
- ASME SA 213 TP 410 Boiler Tube Mechanical Properties
What is ASME SA 213 TP 410 Boiler Tube?
SA 213 TP 410 Stainless Steel Seamless Boiler Tubes is resistant to atmospheric conditions, apart from water and some other chemicals. These 410 SS Welded Boiler Tubes could be used in applications where the environments contain either weak or diluted acetic acid, nitric acid, naphtha, and sulfuric acid. Besides this, stainless steel grade 410 is also resistant to acids found in foods.
ASME SA 213 TP 410 Boiler Tube Price List
| Price of ASME SA 213 TP 410 Boiler Tube manufacturer in India | ASME SA 213 TP 410 Boiler Tubing Price in India (INR) | ASME SA 213 TP 410 Boiler Tube Price in USD | ASTM A213 TP 410 Boiler Tubing Price in UAE Dirham |
|---|---|---|---|
| Austenitic ASTM A213 TP410 seamless tubes | INR 189483.77 - 547080.96 | US $2660-7680 | 9770.13 - 28208.49 UAE Dirham |
| ASTM A213 TP410 Seamless tube | INR 42740.70 - 85481.40 | US $600-1200 | 2203.79 - 4407.58 UAE Dirham |
| SA 213 TP 410 stainless steel tube | INR 269703.50 - 427407.00 | US $3000-6000 | 11018.94 - 22037.88 UAE Dirham |
| ASTM A213 TP410 stainless tube | INR 2849.38 - 8548.14 | US $40-120 | 146.92 - 440.76 UAE Dirham |
Please note This is an approximate Cost of ASME SA 213 TP 410 Boiler Tube in India. Please feel free to contact us for Free Quote and latest ASME SA 213 TP 410 ERW Boiler Tubes price list in India. Also compare our price with other Stainless Steel 410 Welded Boiler Tubes suppliers in India & China.
Types of ASME SA 213 TP 410 Boiler Tube
ASME SA 213 TP 410 Boiler Tube Specification
| ASTM Specification | ASME SA 213 / ASTM A213 |
|---|---|
| Standard | ASTM, ASME, JIS, AISI, AMS, EN, SAE, DIN, NF, TOCT, DS, DTD, GB |
| ASME SA 213 TP 410 Boiler Tube Size | 4 to 219mm W. T.: 0.5 to 20mm |
| ASTM A213 TP 410 Boiler Tubing Size | 5.0 - 1219.2 mm |
| SA 213 TP 410 Stainless Steel EFW Boiler Tube size | 5.0 - 1219.2 mm |
| Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| ASTM A213 410 Boiler Tubing Schedule | SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| ASME SA 213 TP 410 Boiler Tube Length | Single Random, Double Random, Standard & Cut length |
| Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF, NO.1, NO.4, 2B, BA, HL, 8K, Mirror finish, etc |
| Form | ASME SA 213 TP 410 Boiler Tube are available in form of Round, Square, Hollow, Rectangular, Hydraulic, Coiled, Straight Boiler Tubes, “U” Shape, Pan Cake Coils etc. |
| Type of 410 Stainless Steel Boiler Tube | Seamless / ERW/ EFW / Welded / Fabricated / CDW / DOM / CEW ASME SA 213 TP 410 Boiler Tube |
| ASME SA 213 TP 410 Boiler Tube End | Plain End, Beveled End, Threaded, Screwed ends |
| Marking on ASME SA 213 Stainless Steel 410 Boiler Tubing | All ASME SA 213 TP 410 Boiler Tubes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Application of ASME SA 213 TP 410 Boiler Tube | sugar mill, chemical industry, paper mill,textile factory, central heating enterprise, power plant |
| Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| Specialize in | Large Diameter ASME SA 213 TP 410 Boiler Tube |
| ASME SA 213 TP 410 Boiler Tube manufacturing Technique | Cold drawn, hot drawn, bright annealed, solid solution, hot extruding |
| Our stockyard | Ahmedabad, Agra, Dhanbad, Tirunelveli, Bengaluru, Chennai, Mumbai, Hyderabad, Bhubaneswar, Noida, Pimpri-Chinchwad, Shivamogga, Coimbatore, Thiruvananthapuram, Tiruchirappalli, Pune, Navi Mumbai |
| ASME SA 213 TP 410 Boiler Tube Test Certificate | Manufacturer Test Certificate Laboratory Test Certificate from Govt. Approved Lab. Under Third Party Inspection |
| Material Test Certificates (MTC) | Material Test Certificates (MTC) as per EN 10204/3.1B, EN 10204 3.1 and EN 10204 3.2, 100% Radiography Test Report, Heat Treatment Charts, Raw Materials Certificate, Third Party Inspection Report, Fumigation Certificates, ASME SA 213 TP 410 Boiler Tube HS Code Commercial Invoice, Form A for Generalized System of Preferences (GSP) |
| Manufacturers of ASME SA 213 TP 410 Boiler Tube |
|
| We can also cut, thread, and groove ASTM A213 TP 410 Boiler Tube to meet your specifications. ASME SA 213 TP 410 Boiler Tube Dimension ANSI/ ASME B36.10, B36.19, B2.1 | |
ASME SA 213 TP 410 Reheater Tubes Sizes
ASTM A213 TP 410 Boiler Tubes are supplied according to ANSI/ ASME B36.19.
| OUTER DIAMETER (OD) | 10.2 – 139.7 mm (from 26.9 mm manufactured as hot rolled) |
| WALL THICKNESS (WT) | 0.5 – 16.0 mm (from 2.6 mm manufactured as hot rolled) |
| Types of supplied length of stainless steel boiler tubes are: | (a) random length, |
| Stainless Steel Boiler Tube | (b) fixed length ± 500 mm, |
| (c) exact length L < 6 m 0 + 10 mm L = 6 – 12 m 0 + 15 mm. L > 12 m + upon agreement |
Buy from PED certified ASME SA 213 TP 410 Boiler Tube suppliers for prime quality & low price.
SA 213 TP 410 Stainless Steel Seamless Boiler Tubes Pressure Rating
| AVE. WALL INCHES | MIN YIELD STRENGTH (PSI) | MIN TENSILE STRENGTH (PSI) | THEORETICAL BURST PRESSURE * (PSI) | WORKING PRESSURE (PSI) 25% OF BURST | THEORETICAL YIELD POINT ** (PSI) | COLLAPSE PRESSURE *** (PSI) | |
|---|---|---|---|---|---|---|---|
| 0.250 | 0.020 | 30,000 | 75,000 | 14,286 | 3,571 | 5,714 | 4,416 |
| 0.250 | 0.028 | 30,000 | 75,000 | 21,649 | 5,412 | 8,660 | 5,967 |
| 0.250 | 0.035 | 30,000 | 75,000 | 29,167 | 7,292 | 11,667 | 7,224 |
| 0.250 | 0.049 | 30,000 | 75,000 | 48,355 | 12,089 | 19,342 | 9,455 |
| 0.250 | 0.065 | 30,000 | 75,000 | 81,250 | 20,313 | 32,500 | 11,544 |
| 0.375 | 0.020 | 30,000 | 75,000 | 8,955 | 2,239 | 3,582 | 3,029 |
| 0.375 | 0.028 | 30,000 | 75,000 | 13,166 | 3,292 | 5,266 | 4,145 |
| 0.375 | 0.035 | 30,000 | 75,000 | 17,213 | 4,303 | 6,885 | 5,077 |
| 0.375 | 0.049 | 30,000 | 75,000 | 26,534 | 6,634 | 10,614 | 6,816 |
| 0.375 | 0.065 | 30,000 | 75,000 | 39,796 | 9,949 | 15,918 | 8,597 |
| 0.500 | 0.020 | 30,000 | 75,000 | 6,522 | 1,630 | 2,609 | 2,304 |
| 0.500 | 0.028 | 30,000 | 75,000 | 9,459 | 2,365 | 3,784 | 3,172 |
| 0.500 | 0.035 | 30,000 | 75,000 | 12,209 | 3,052 | 4,884 | 3,906 |
| 0.500 | 0.049 | 30,000 | 75,000 | 18,284 | 4,571 | 7,313 | 5,304 |
| 0.500 | 0.065 | 30,000 | 75,000 | 26,351 | 6,588 | 10,541 | 6,786 |
| 0.500 | 0.083 | 30,000 | 75,000 | 37,275 | 9,319 | 14,910 | 8,307 |
| 0.625 | 0.020 | 30,000 | 75,000 | 5,128 | 1,282 | 2,051 | 1,859 |
| 0.625 | 0.028 | 30,000 | 75,000 | 7,381 | 1,845 | 2,953 | 2,568 |
| 0.625 | 0.035 | 30,000 | 75,000 | 9,459 | 2,365 | 3,784 | 3,172 |
| 0.625 | 0.049 | 30,000 | 75,000 | 13,947 | 3,487 | 5,579 | 4,335 |
| 0.625 | 0.065 | 30,000 | 75,000 | 19,697 | 4,924 | 7,879 | 5,591 |
| 0.625 | 0.083 | 30,000 | 75,000 | 27,124 | 6,781 | 10,850 | 6,910 |
| 0.625 | 0.095 | 30,000 | 75,000 | 32,759 | 8,190 | 13,103 | 7,734 |
| 0.625 | 0.109 | 30,000 | 75,000 | 40,172 | 10,043 | 16,069 | 8,639 |
| 0.750 | 0.028 | 30,000 | 75,000 | 6,052 | 1,513 | 2,421 | 2,156 |
| 0.750 | 0.035 | 30,000 | 75,000 | 7,721 | 1,930 | 3,088 | 2,669 |
| 0.750 | 0.049 | 30,000 | 75,000 | 11,273 | 2,818 | 4,509 | 3,664 |
| 0.750 | 0.065 | 30,000 | 75,000 | 15,726 | 3,931 | 6,290 | 4,749 |
| 0.750 | 0.083 | 30,000 | 75,000 | 21,318 | 5,330 | 8,527 | 5,905 |
| 0.750 | 0.095 | 30,000 | 75,000 | 25,446 | 6,362 | 10,179 | 6,637 |
| 0.750 | 0.109 | 30,000 | 75,000 | 30,733 | 7,683 | 12,293 | 7,453 |
| 0.750 | 0.120 | 30,000 | 75,000 | 35,294 | 8,824 | 14,118 | 8,064 |
| 0.875 | 0.020 | 30,000 | 75,000 | 3,593 | 898 | 1,437 | 1,340 |
| 0.875 | 0.028 | 30,000 | 75,000 | 5,128 | 1,282 | 2,051 | 1,859 |
| 0.875 | 0.035 | 30,000 | 75,000 | 6,522 | 1,630 | 2,609 | 2,304 |
| 0.049 | 30,000 | 75,000 | 9,459 | 2,365 | 3,784 | 3,172 | |
| 0.875 | 0.065 | 30,000 | 75,000 | 13,087 | 3,272 | 5,235 | 4,126 |
| 0.875 | 0.083 | 30,000 | 75,000 | 17,560 | 4,390 | 7,024 | 5,152 |
| 0.875 | 0.095 | 30,000 | 75,000 | 20,803 | 5,201 | 8,321 | 5,807 |
| 0.875 | 0.109 | 30,000 | 75,000 | 24,886 | 6,221 | 9,954 | 6,543 |
| 0.875 | 0.120 | 30,000 | 75,000 | 28,346 | 7,087 | 11,339 | 7,100 |
| 1.000 | 0.028 | 30,000 | 75,000 | 4,449 | 1,112 | 1,780 | 1,633 |
| 1.000 | 0.035 | 30,000 | 75,000 | 5,645 | 1,411 | 2,258 | 2,027 |
| 1.000 | 0.049 | 30,000 | 75,000 | 8,149 | 2,037 | 3,259 | 2,796 |
| 1.000 | 0.065 | 30,000 | 75,000 | 11,207 | 2,802 | 4,483 | 3,647 |
| 1.000 | 0.083 | 30,000 | 75,000 | 14,928 | 3,732 | 5,971 | 4,567 |
| 1.000 | 0.095 | 30,000 | 75,000 | 17,593 | 4,398 | 7,037 | 5,159 |
| 1.000 | 0.109 | 30,000 | 75,000 | 20,908 | 5,227 | 8,363 | 5,827 |
| 1.000 | 0.120 | 30,000 | 75,000 | 23,684 | 5,921 | 9,474 | 6,336 |
| 1.000 | 0.134 | 30,000 | 75,000 | 27,459 | 6,865 | 10,984 | 6,963 |
| 1.250 | 0.035 | 30,000 | 75,000 | 4,449 | 1,112 | 1,780 | 1,633 |
| 1.250 | 0.049 | 30,000 | 75,000 | 6,380 | 1,595 | 2,552 | 2,260 |
Robost quality ASME SA 213 TP 410 Boiler Tube suppliers offer these SA 213 TP 410 Stainless Steel Shell And Tube Heat Exchangers in a wide range of sizes, from thin wall to thick wall ASME SA 213 TP 410 Boiler Tube in seamless or welded forms.
SS 410 Helical Tube Heat Exchanger, ASME SA 213 410 Boiler Reheater Tubes suppliers in India. 410 Stainless Steel Reheater Tubes stockholder, SA 213 Stainless Steel 410 Erw Boiler Tubes manufacturers. SA 213 410 Double Tube Heat Exchanger wholesaler in Mumbai.
| ASME SA 213 TP 410 Boiler Tube | SA 213 TP 410 Stainless Steel Boiler Tubing |
| SA 213 TP 410 Stainless Steel Reheater Tubes | ASTM A213 410 Boiler Reheater Tubes |
| ASTM A213 410 Seamless Boiler Tubes | ASTM A213 410 ERW Boiler Tubes |
| SA 213 TP 410 Stainless Steel Welded Boiler Tubes | Stainless Steel 410 Finned Tube Reheater |
| ASTM A213 410 Heat Exchanger Tube | SS UNS S41000 Heat Exchanger Tubes |
| Stainless Steel 410 Heat Exchanger Tubing | SA 213 TP 410 UNS S41000 Shell And Tube Heat Exchangers |
| SS UNS S41000 Seamless Heat Exchanger Tube | ASME SA 213 410 Welded Heat Exchanger Tube |
| ASME SA 213 TP 410 Coiled Tube Heat Exchanger | ASTM A213 TP 410 Double Tube Heat Exchanger |
| SA 213 TP 410 UNS S41000 Boiler Reheater Tubes | 410 Stainless Steel Coiled Tube Heat Exchanger |
| A213 TP 410 UNS S41000 Finned Tube Reheater | ASME SA 213 TP 410 Helical Tube Heat Exchanger |
| ASME SA 213 410 Seamless Boiler Tubes | ASME SA 213 Stainless Steel 410 Double Tube Heat Exchanger |
| 410 Stainless Steel ERW Boiler Tubes | A213 TP 410 Stainless Steel Industrial Shell And Tube Heat Exchanger |
| ASME SA 213 Stainless Steel 410 Welded Boiler Tubes | WNR 1.4006 Jacketed Tube Heat Exchanger |
| A213 TP 410 Stainless Steel Micro Tube Heat Exchanger | SA 213 TP 410 Multi Tube Heat Exchanger |
| WNR 1.4006 Seamless Heat Exchanger Tube | A213 Stainless Steel 410 Welded Heat Exchanger Tube |
| SA 213 TP 410 Boiler Reheater Tubes | A213 TP 410 UNS S41000 ERW Boiler Tubes |
| A213 Stainless Steel 410 Boiler Tubing | ASTM A213 410 Heat Exchanger Tubes |
| ASTM A213 TP 410 Boiler Tube | ASME SA 213 TP 410 Heat Exchanger Tubing |
SS UNS S41000 Boiler Tubes Chemical Composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 410 | 0.15 max | 1.0 max | 1.0 max | 0.040 max | 0.030 max | 11.5 – 13.5 | – | 0.50 max | – |
ASME SA 213 TP 410 Boiler Tube Mechanical Properties
| Grade | Tensile Strength ksi (MPa) min | Yield Strength 0.2% offset ksi (MPa) min | Elongation (% in 50mm) min | Hardness (Brinell) MAX | Hardness (Rockwell B) MAX |
| 410 | 65 (450) | 30 (205) | 20 | 217 | 96 |
Equivalent Grades for ASME SA 213 410 Boiler Tube
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 410 | 1.4006 | S41000 | SUS 410 | 410S21 | – | – | X12Cr13 |
