SA 199 T11 Condenser Tube and A199 Grade T11 Boiler Tubes manufacturer in India

ASTM A199 Heat Exchanger Tubes suppliers and exporters in India

The ASTM A199 Heat Exchanger Tubes are primarily used for constructing heat exchanger equipment. These are mainly used in the process industries such as oil refineries and petrochemical plants. The SA 199 T11 Condenser Tube is heavily demanded in gas condensers due to its physical and mechanical properties.

We are one of the top manufacturers and distributors of A199 Grade T11 Boiler Tubes in India. We offer products that are high in quality and affordable in price. We offer a fully customized Annealed ASTM A199 T22 U Tube Heat Exchanger to be used in various industries. Our clients are based in different parts of the world and happy with our services. We offer different surface treatments on the A199M Cold Drawn Tube, like oil-dip, shot blasting, varnish, etc. We can also paint the ASME SA199 Steam Tube Boiler as requested by our clients.

The ASTM A199 T5 Heat Exchanger Tube has a wide range of applications. Apart from being used in heat exchangers, these are also popularly used in various construction projects, like residents, labs, and commercial buildings. The sturdy and tough nature of the ASTM A 199 Superheater Tube makes it ideal for industrial buildings. Clients can get these tubes in seamless, welded, and casting variants.

Clients looking for a high-quality A199 t9 Fire Tube Boiler can contact us. Our products can process seamlessly under the following conditions:

  1. High-temperature environment
  2. A surrounding with aggressive media like acid
  3. High Pressure

We have a team of experienced professionals who supervise the whole process and help to maintain the quality and dimensional accuracy of the products.

Table of Content

Annealed ASTM A199 T22 U Tube Heat Exchanger and A199M Condenser Tubes supplier in India

ASTM A199 Heat Exchanger Tubes Specification

Standards ASTM, ASME and API
Size 1/2” NB to 36” NB
Craft Cold rolled / Cold drawn
Type Seamless / ERW / Welded / Fabricated
Thickness 3-12mm
Specialized in Large Diameter ASTM A192 Pipe
Form Round, Hydraulic Etc
Length Min 3 Meters, Max18 Meters, or according to customer’s requirement
End Plain End, Beveled End, Treaded

Different methods used by manufacturers'

Extrusion, CDW, Cold Drawn Seamless (CDS), Electro Fusion Seam Welded (EFSW), Fabricated, 100% X Ray/ Gamma Ray Welded, Welded, Submerged Arc Welded (SAW), Longitudinally Submerged Arc Welded (LSAW), Seamless, Hot Finish Seamless (HFS), Horizontal Submerged Arc Welded (HSAW), Electric Resistance Welded (ERW)
Test

Charpy V-Notch Test, Charpy V Impact Test, Non Destructive Testing , Hardness Test, Hydro test, Hardness, Metallurgical & Stereo Microscopy, Mechanical, Flux Leakage examination or Magnetic Flaw detection, SSC- Sulfide Stress Corrosion Cracking, Creep, Tensile, Macro, Burst Test, Radiography, Chemical, Fine Grain, NACE MR0175, Stress , Ultrasonic Test, Straightness, Ferrite, Eddy current, Micro, Bend TestBend test / Guided Bend, Impact, HIC- Hydrogen-induced Cracking, Positive Material Identification (PMI), Surface Roughness Test, TM0177, H2 SERVICE, Ultrasonic, TM0284, IGC- Intergranular Corrosion Test, Salt Spray Test to test Phosphating
Additional Services and Facility Sawing, Laser/ Water Jet Cutting, Cutting, Beveling, Tapping, Polishing, Threading
Additional Testing By Manufacturer NACE MR0175, SSC TEST,NACE TM0177, HIC TEST, NACE TM0284, H2 SERVICE, IBR, etc.
Schedules SCH 160, SCH 40, SCH 80, SCH XXS, SCH XS, All Schedules
Origin European, Japanese, Korean, US, Russian, Indian (Strictly No Chinese Material)
Tolerance Cold drawn pipe: +/-0.1mm
Cold rolled pipe: +/-0.05mm

Buy ASTM A199 Tubing in Germany, UK, Australia, Nigeria, Philippines,Korea, Qatar, UAE, USA, Malaysia, Singapore, Vietnam, Saudi Arabia, Indonesia at dealer price, ask for a free sample now!

Size Range of A199 t9 U Bend Heat Exchanger Tube

Size OD Nominal Wall Outside Diameter Length Wall
1/2" (12.7) 0.065" (1.65)/0.049" (1.25) +/-0.005 (0.13) +1/8" (3.18) - 0 +/-10.0%
3/4" (19.1) 0.065" (1.65)/0.049" (1.25) +/-0.005 (0.13) +1/8" (3.18) - 0 +/-10.0%
1" (25.4) 0.065" (1.65)/0.049" (1.25) +/-0.005 (0.13) +1/8" (3.18) - 0 +/-10.0%
1-1/2" (38.1) 0.065" (1.65)/0.049" (1.25) +/-0.008" (0.20) +1/8" (3.18) - 0 +/-10.0%
2" (50.8) 0.065" (1.65)/0.049" (1.25) +/-0.008" (0.20) +1/8" (3.18) - 0 +/-10.0%
2-1/2" (63.5) 0.065" (1.65) +/-0.010" (0.25) +1/8" (3.18) - 0 +/-10.0%
3" (76.2) 0.065" (1.65) +/-0.010" (0.25) +1/8" (3.18) - 0 +/-10.0%
4" (101.6) 0.083" (2.11) +/-0.015" (0.38) +1/8" (3.18) - 0 +/-10.0%
6" (152.4) 0.083" (2.11) +/-0.030" (0.76) +1" (25.4) - 0 +/-10.0%
6" (152.4) 0.109" (2.77) +/-0.030" (0.76) +1" (25.4) - 0 +/-10.0%
8" (203.2) 0.109" (2.77) +0.061" (1.55)/-0.031" (0.79) +1" (25.4) - 0 +/-10.0%

ASTM A199 Alloy Steel Tube Dimensions

DN NPS(Inch) D(mm) SCH5S SCH10S SCH40S STD SCH40 SCH80 XS SCH80S SCH160 XXS
6 1/8 10.30 - 1.24 1.73 1.73 1.73 2.41 2.41 2.41 - -
8 1/4 13.70 - 1.65 2.24 2.24 2.24 3.02 3.02 3.02 - -
10 3/8 17.10 - 1.65 2.31 2.31 2.31 3.20 3.20 3.20 - -
15 1/2 21.30 1.65 2.11 2.77 2.77 2.77 3.73 3.73 3.73 4.78 7.47
20 3/4 26.70 1.65 2.11 2.87 2.87 2.87 3.91 3.91 3.91 5.56 7.82
25 1 33.40 1.65 2.77 3.38 3.38 3.38 4.55 4.55 4.55 6.35 9.09
32 1 1/4 42.20 1.65 2.77 3.56 3.56 3.56 4.85 4.85 4.85 6.35 9.70
40 1 1/2 48.30 1.65 2.77 3.68 3.68 3.68 5.08 5.08 5.08 7.14 10.15
50 2 60.30 1.65 2.77 3.91 3.91 3.91 5.54 5.54 5.54 8.74 11.07

Manufacturing Types of ASTM A 199 Alloy Round Tube

ASME SA199 Tube

ASME SA199 Tube

ASTM A199 Cold-Drawn Seamless Tube

ASTM A199 Cold-Drawn Seamless Tube

A199M U Tube

A199M U Tube

ASTM A 199 Alloy Seamless Tube

ASTM A 199 Alloy Seamless Tube

A199 T5 Boiler Tube

A199 T5 Boiler Tube

A199 T11 Heat Exchanger Tube

A199 T11 Heat Exchanger Tube

Price List of ASTM A199 Heat Exchanger Tubes

Products Price
A199 Alloy High Pressure Seamless Steel Tube $650 Per Ton
ASTM A199-T9 Alloy Steel Seamless Tube $620 Per Ton
ASTM A199 Alloy Steel Tube (O. D 19.05-101.6mm) $7.6 Per kg
ASTM A199 T5 42 Inch Tube $1000 Per Ton

Many A199 T11 Boiler Tube importers, dealers, traders, stockholders, distributors, retailer, suppliers, wholesaler, stockist, exporters, prefer to buy ASME Sa199 T5 material from Vishal Steel India and supply ASTM A199 Fire Tube in their own countries with higher margins, so buy directly from Vishal Steel India to save your cost, contact us for a free quote !!!

Chemical analysis of ASTM A199 Tube

Steel grade WT C Mn P
(max)		 S
(max)		 Si Cr Mo
ASTM A199/T4 MW 0.15MAX 0.30-0.60 0.03 0.03 0.50-1.00 2.15-2.85 0.44-0.65
ASTM A199/T5 MW 0.50-0.15 0.30-0.60 0.03 0.03 0.50MAX 4.00-6.00 0.45-0.65
ASTM A199/T7 MW 0.15MAX 0.30-0.60 0.03 0.03 0.50-1.00 6.00-8.00 0.45-0.65
ASTM A199/T9 MW 0.15MAX 0.30-0.60 0.03 0.03 0.25-1.00 8.00-10.0 0.90-1.10
ASTM A199/T11 MW 0.50-0.15 0.30-0.60 0.03 0.03 0.50-1.00 1.00-1.50 0.44-0.65
ASTM A199/T22 MW 0.50-0.15 0.30-0.60 0.03 0.03 0.50MAX 1.90-2.60 0.87-1.13

Mechnical Properties of ASTM A199 Boiler Tube

Steel grade Tensile Strength
(Mpa)		 Yield Strength
(Mpa)		 Elongation
(%)		 SPECIFIC REQUIREMENT
ASTM A199/T4 415MIN 170MIN 30/22 Hardness 85 HRB MAX
ASTM A199/T5 415MIN 170MIN 30/22 Hardness 85 HRB MAX
ASTM A199/T7 415MIN 170MIN 30/22 Hardness 85 HRB MAX
ASTM A199/T9 415MIN 170MIN 30/22 Hardness 85 HRB MAX
ASTM A199/T11 415MIN 170MIN 30/22 Hardness 85 HRB MAX
ASTM A199/T22 415MIN 170MIN 30/22 Hardness 85 HRB MAX

Check composition and mechanical properties of ASME SA199 Steam Tube Boiler, buy ASTM A199 T5 Heat Exchanger Tube at low cost in Mumbai

Equivalent Grade of ASME SA199 High Pressure Tube

ASTM STANDARD UNS NO. KOREA/JAPANES GERMAN BRITISH BELGIAN FRENCH ITALIAN
KS/JIS Symbol KS/JIS Numbe Remarks DIN Type DIN

Number		 Materiral

Number		 Remarks B.S

Number		 B.S Grade Remarks NBN Type NBN Grade Remarks AFNOR Type NF Number Ramarks UNI Type UNI Number Ramarks
T5 K41545 STHA 24 / STBA 25 D3572 / G3462 (35) 12 CrMo 19 5 1.7362 (3a) 3606 CFS 625 (35) X 12 Cr Mo 5 837 (35) Z 12 CD 5.05 (3a) (3); dalmine 234
T11 K11597 STHA 22 / STBA 23 D3572 / G3462 (35) 13 CrMo 44 17175 1.7335 (8) 3606 CFS 621 (35) 10 CD 5.05 (3a) (3); dalmine 227(10)
T22 K21590 STHA 23 / STBA 24 D3572 / G3462 (35) 10 CrMo 9 10 17175 1.7380 3606 CFS 622 (35) 10 Cr Mo 9 10 837 (35) 10 CD 9.10 (3a) 12CrMo 9 10 5462 (10)0

ASTM SA199 Seamless Tube Stock List

A199 t9 Triangle Tube Boiler A199M Boiler Fin Tubes
ASTM A199 T11 Tube Boiler ASTM A 199 Alloy U Bend Heat Exchanger Tubes
ASTM A199 T22 Boiler Tubing A199 T5 Finned Tubes
ASTM A199 T5 Water Tube Steam Boiler A199 T11 Shell Tube Heat Exchanger
SA199 T5 Steam Tube Boiler A199 T22 U Tube Heat Exchanger
SA199 T11 Seamless Boiler Tubes A199 t9 Fire Tube
SA199 T22 Economiser Tubes ASTM A199 T11 Superheater Tube Material
SA199 t9 Bent Boiler Tube ASTM A199 T22 U Tube Exchanger
ASME SA199 U Tube Bundle Heat Exchanger ASTM A199 T5 Boiler Superheater Tube Material
ASTM A199 Superheater Tubes SA199 T5 Fin Tube Boiler

Tolerance of ASME SA 199 Tube

Outside Diamter, mm
Tolerance, %

3.2≤OD＜38.1
+20/-0
38.1≤OD≤76.2
+22/-0

Outside Diameter Tolerance of A199 T11 Tubing

OD
In. (mm)

 Permissible Variations In. (mm)
Over (+)

Under (-)

Under 1 (25.4)

 0.004 (0.1) 0.004 (0.1)

1 to 1 ½ (25.4 to 38.1), Incl

 0.006 (0.15) 0.006 (0.15)

Over 11⁄2 to 2 [38.1 to 50.8], Excl

 0.008 (0.2) 0.008 (0.2)
2 to 21⁄2 [50.8 to 63.5], Excl 0.010 (0.25)

0.010 (0.25)
21⁄2 to 3 [63.5 to 76.2], Excl 0.012 (0.3)

0.012 (0.3)

ASTM A 199 Alloy Large Diameter Tube Cut Length Tolerance

Cold-Finished Seamless Tubes
OD,
In.(mm)		 Cut Length, in.(mm)
Over(+) Under(-)
All Sizes 3⁄16 [5] 0 [0]
Under 2 [50.8] 1⁄8 [3] 0 [0]
2 [50.8] and over 3⁄16 [5] 0 [0]
Under 2 [50.8] 1⁄8 [3] 0 [0]
2 [50.8] and over 3⁄16 [5] 0 [0]

Pressure Rating of ASTM A199 T5 Welded Tube

Maximum Allowable Pressure (psi)
NPS Outside Diameter Schedule
(in) (in) 10 20 30 STD 40 60 XS 80 100 120 140 160 XXS
1/4 0.54 7985 7985 10798 10798
3/8 0.675 6606 6606 9147 9147
1/2 0.84 6358 6358 8575 8575 10908 17150
3/4 1.05 5273 5273 7187 7187 10220 14373
1 1.315 4956 4956 6670 6670 9316 13340
1 1/4 1.66 4133 4133 5638 5638 7380 11276
1 1/2 1.9 3739 3739 5158 5158 7247 10316
2 2.375 3177 3177 4498 4498 7097 8995
2 1/2 2.875 3460 3460 4704 4704 6391 9408
3 3.5 3024 3024 4200 4200 6132 8400
3 1/2 4 2769 2769 3896 3896
4 4.5 2581 2581 3670 3670 4769 5782 7339
5 5.563 2273 2273 3303 3303 4404 5505 6606
6 6.625 2071 2071 3195 3195 4157 5318 6390
8 8.625 1420 1574 1829 1829 2307 2841 2841 3375 4085 4613 5147 4971
10 10.75 1140 1399 1664 1664 2279 2279 2708 3277 3847 4558 5128 4558
12 12.75 961 1268 1441 1560 2160 1922 2644 3244 3843 4324 5042 3843
14 14 875 1092 1313 1313 1533 2079 1750 2625 3283 3829 4375 4921
16 16 766 956 1148 1148 1531 2009 1531 2585 3157 3733 4404 4882
18 18 681 849 1192 1021 1530 2042 1361 2553 3147 3743 4252 4848
20 20 613 919 1225 919 1455 1989 1225 2526 3138 3675 4288 4824
22 22 557 835 1114 835 1949 1114 2506 3063 3619 4176 4733
24 24 510 766 1147 766 1405 1978 1021 2489 3126 3700 4210 4786
30 30 510 817 1021 613 817
32 32 478 766 957 574 1054
34 34 450 721 901 540 992
36 36 425 681 851 510 1021
42 42 583 729 438 875

Types of ASTM A199 Heat Exchanger Tubes

A199 T22 Fire Tube Boiler

A199 T22 Fire Tube Boiler

ASME SA199 Bent Tube Boiler

ASME SA199 Bent Tube Boiler

A199 T11 Small Bore Tube

A199 T11 Small Bore Tube

A199M Round Tube

A199M Round Tube

ASTM A199 T5 Tube Material

ASTM A199 T5 Tube Material

A199 T5 Condenser Tubes

A199 T5 Condenser Tubes

A199 t9 Hot Finished Tube

A199 t9 Hot Finished Tube

SA199 T11 U Tube Type Heat Exchanger

SA199 T11 U Tube Type Heat Exchanger

SA199 t9 Water Tube Boiler

SA199 t9 Water Tube Boiler

ASTM A199 High Pressure Tube

ASTM A199 High Pressure Tube

SA199 T22 U Bundle Heat Exchanger

SA199 T22 U Bundle Heat Exchanger

SA199 T22 IBR Tube

SA199 T22 IBR Tube

ASTM A199 T22 U Tube Heat Exchanger

ASTM A199 T22 U Tube Heat Exchanger

SA199 T5 Cold Drawn Tube

SA199 T5 Cold Drawn Tube

A199 T22 U Tube Bundle

A199 T22 U Tube Bundle

ASTM A199 T11 Tubing

ASTM A199 T11 Tubing

SA199 T11 Seamless Tubing

SA199 T11 Seamless Tubing

ASTM A 199 Alloy Large Diameter Tube

ASTM A 199 Alloy Large Diameter Tube

Manufacturer of ASTM A 199 Alloy Round Tube and A199 t9 Fire Tube Boiler in India, view ready stock list

Marking of SA 199 T11 Condenser Tube

Marking on A199 T5 Boiler Tube

  • A199M U Tube Manufacturer’s name
  • Monogram marking
  • A199M Grade and type
  • Heat treatment
  • Impact test temperature
  • Manufacturing process
  • Weight
  • End finish of SA199 t9 Tubes
  • ASTM A199 T11 material Heat treatment
  • Type of SA199 T5 Tube thread
  • ASME A199 T11 Tubing Grade and type
  • Impact test temperature
Low Alloy A199 T11 Large Diameter Tube

Different manufacturing processes of A199 Grade T11 Boiler Tubes

  • ASME SA199 T22 Hot Finished Seamless (HFS)
  • SA199 T11 Gr Electric Resistance Welding (ERW)
  • A199 Grade T5 Cold Drawn or Finished Seamless (CDS)
  • A199 Gr T11 T9 High Frequency Induction Welding (HFIW)
  • SA 199 Grade T22 Hand-Welding or Manual Arc Welding (MAW) Tube
  • A199 Gr T4 Hot Finished Welding (HFW) Tube
  • ASTM A199M Grade T22 Cold Drawn Electric Resistance Welding (CEW) Tube
  • IBR Approved SA199 t9 Electric Fusion Welding (EFW) Tube
  • Ferritic Low A199 T11 Sub-merged Arc Welding (SAW) Tube
  • IBR Certified ASME SA199 Gr T22 Oxy Acetylene Welding (OAW) Tube
SA199 T22 Superheater Tubes

Test Requirements of ASME SA199 Steam Tube Boiler

  • A199 T5 material Eddy Current Test
  • ASME SA199 Tubing Ultrasonic Testing
  • Hydrostatic Tests for ASTM A 199 Alloy Tube
  • Metalography Test performed for ASTM A199 T11 Tubing
  • ASTM A199 T5 material MP / DP / RF ECT Testing
  • BHN Hardness & Rockwell Testers
  • Visual Inspection, TPP and CVN Impact Testing
ASTM A 199 Alloy Steel Tube

A199 Cold drawn heat exchangers tubes wall thickness

Outside Minimum wall thickness
diameter BWG (inch) 20 (.035) 18 (.049) 16 (.065) 14 (.083) 13 (.095) 12 (.109) 11 (.120) 10 (.134) 9 (.148) 8 (.165) 7 (.180) 6 (.203) 5 (.220)
[mm] [inch]
[mm]
 0,89 1,24 1,65 2,11 2,41 2,77 3,05 3,40 3,76 4,19 4,57 5,16 5,59
1/2 lb/ft 0,190 0,256 0,327 0,399 0,441 0,487 0,519 0,555 0,586
12,70 .500 kg/m 0,283 0,381 0,487 0,594 0,657 0,725 0,773 0,826 0,873
5/8 lb/ft 0,242 0,328 0,423 0,521 0,581 0,647 0,696 0,752 0,804
15,88 .625 kg/m 0,360 0,488 0,630 0,776 0,865 0,964 1,036 1,120 1,198
3/4 lb/ft 0,400 0,518 0,643 0,720 0,807 0,872 0,948 1,021
19,05 .750 kg/m 0,595 0,771 0,957 1,072 1,202 1,299 1,412 1,521
7/8 lb/ft 0,472 0,614 0,767 0,864 0,973 1,056 1,158
22,23 .875 kg/m 0,702 0,913 1,141 1,285 1,448 1,571 1,722
1 lb/ft 0,543 0,709 0,887 0,998 1,128 1,225 1,342 1,456 1,587 1,696
25,40 1.000 kg/m 0,808 1,056 1,321 1,487 1,680 1,824 1,998 2,169 2,363 2,526
1 1/4 lb/ft 0,686 0,900 1,131 1,277 1,448 1,577 1,734 1,891 2,071 2,225 2,451 2,607
31,75 1.250 kg/m 1,022 1,340 1,684 1,902 2,157 2,349 2,583 2,816 3,085 3,313 3,650 3,882
1 1/2 lb/ft 0,830 1,090 1,375 1,556 1,769 1,930 2,128 2,326 2,556 2,753 3,047 3,253
38,10 1.500 kg/m 1,236 1,624 2,048 2,317 2,634 2,875 3,169 3,464 3,807 4,100 4,538 4,845
2 lb/ft 1,472 1,863 2,114 2,409 2,636 2,914 3,196 3,525 3,810 4,241 4,547
50,80 2.000 kg/m 2,192 2,775 3,148 3,588 3,925 4,340 4,759 5,250 5,674 6,316 6,771
2 1/2 lb/ft 1,854 2,351 2,671 3,050 3,341 3,701 4,066 4,494 4,867 5,435 5,839
63,50 2.500 kg/m 2,761 3,502 3,978 4,542 4,976 5,512 6,055 6,693 7,249 8,094 8,696
3 lb/ft 2,840 3,228 3,691 4,047 4,487 4,935 5,464 5,924 6,628 7,132
76,20 3.000 kg/m 4,229 4,808 5,497 6,027 6,683 7,350 8,137 8,823 9,871 10,622
a
a

Cold drawn heat exchangers tubes with average wall thickness (sizes in inches)
aaa
Outside Average wall thickness
diameter BWG (inch) 20 (.035) 18 (.049) 16 (.065) 14 (.083) 13 (.095) 12 (.109) 11 (.120) 10 (.134) 9 (.148) 8 (.165) 7 (.180) 6 (.203) 5 (.220)
[mm] [inch]
[mm]
 0,89 1,24 1,65 2,11 2,41 2,77 3,05 3,40 3,76 4,19 4,57 5,16 5,59
1/2 lb/ft 0.173 0.236 0.302 0.369 0.410 0.445 0.487 0.523 0.557
12,70 .500 kg/m 0,259 0,351 0,450 0,551 0,612 0,678 0,726 0,780 0,829
5/8 lb/ft 0.220 0.301 0.388 0.480 0.537 0.600 0.647 0.703 0.754
15,88 .625 kg/m 0,328 0,447 0,579 0,716 0,801 0,897 0,965 1,046 1,124
3/4 lb/ft 0.267 0.366 0.475 0.591 0.664 0.745 0.807 0.881 0.952
19,05 .750 kg/m 0,398 0,547 0,708 0,881 0,989 1,110 1,203 1,312 1,418
7/8 lb/ft 0.432 0.562 0.702 0.791 0.891 0.967 1.060
22,23 .875 kg/m 0,643 0,836 1,045 1,177 1,326 1,439 1,577
1 lb/ft 0.497 0.649 0.812 0.918 1.037 1.128 1.239 1.346 1.471 1.575
25,40 1.000 kg/m 0,740 0,966 1,212 1,366 1,550 1,681 1,845 2,006 2,192 2,347
1 1/4 lb/ft 0.628 0.822 1.034 1.172 1.328 1.448 1.597 1.741 1.912 2.056 2.272 2.417
31,75 1.250 kg/m 0,933 1,225 1,542 1,744 1,980 2,159 2,377 2,595 2,848 3,063 3,383 3,606
1 1/2 lb/ft 0.759 0.996 1.256 1.426 1.619 1.769 1.955 2.137 2.353 2.537 2.814 3.009
38,10 1.500 kg/m 1,127 1,483 1,870 2,121 2,413 2,636 2,909 3,184 3,504 3,779 4,191 4,481
2 lb/ft 1.343 1.699 1.933 2.201 2.409 2.670 2.929 3.246 3.499 3.896 4.185
50,80 2.000 kg/m 2,000 2,533 2,876 3,281 3,591 3,974 4,362 4,816 5,210 5,807 6,232
2 1/2 lb/ft 1.690 2.143 2.440 2.783 3.050 3.385 3.717 4.126 4.460 4.980 5.360
63,50 2.500 kg/m 2,517 3,194 3,631 4,148 4,547 5,039 5,539 6,128 6,641 7,424 7,983
3 lb/ft 2.586 2.947 3.365 3.691 4.102 4.508 5.006 5.421 6.064 6.536
76,20 3.000 kg/m 3,855 4,385 5,016 5,502 6,104 6,717 7,440 8,072 9,040 9,734
Supplier of A199 T11 U Tube Bundle and SA199 Superheater Tubes for high pressure and high temperature applications

ASTM A 199 Alloy Round Tube Application

  • Infrastructure
  • Hydraulic, Boiler and Heat Exchanger
  • Idlers and Conveyors
  • Oil and Gas
  • Water Line
  • Ship Building
  • Fluid Transportation
  • Mechanical Purpose
  • Drilling and Minning

A199 t9 Fire Tube Boiler Surface treatment

  • Oil-dip
  • Varnish
  • Passivation
  • Phosphating
  • Shot Blasting

Our Products

Standards

Quick Links
